How to Install Your Washing Machine (Part 2): Water Hose, Drain Hose and Power Connection
Once the machine is placed correctly and the feet are balanced, the next stage of installation focuses on connecting the water supply, setting the drain hose, and ensuring a safe power connection. These steps are essential for the machine to function smoothly without leaks, drainage issues, or electrical problems. The following guide walks you through the remaining installation steps shown in the visual instructions.
1. Check the Water Supply
Before attaching any hoses, always test the water tap that will feed the washing machine. Turn the tap on to make sure the water flow is strong and consistent. A weak flow can affect washing performance and may indicate a blocked tap filter or a plumbing issue that needs attention. Confirming this early helps prevent future interruptions.
2. Connect the Water Hose to the Tap
Once you verify the water flow, take the inlet hose from the installation kit and attach it securely to the tap. Tighten the connection by hand or with a suitable tool, but avoid overtightening, as this may damage the threads. The goal is to create a tight seal that prevents water leaks during operation. If the connection feels loose, check the rubber gasket inside the hose for proper placement.
3. Attach the Hose to the Machine’s Water Inlet
Move to the back of your washing machine and locate the water inlet valve. Connect the other end of the hose to this valve and tighten it properly. The connection should feel firm, but gentle enough not to strain the plastic components. After securing the hose, pull it slightly to ensure it is seated correctly.
4. Confirm the Hose Position
Once the hose is attached at both ends, check that it is not bent, kinked, or twisted. A twisted hose restricts water flow, which may cause error messages during the wash cycle. Keep the hose in a smooth position so water can pass easily from the tap to the machine.
5. Set the Drain Hose
Next, prepare the drainage connection. Insert the washing machine’s drain hose into the waste pipe. The guide indicates a maximum insertion depth of 15 cm. Pushing the hose too far can cause poor drainage or backflow, so this measurement is important. Keep the hose stable within the pipe but not overly tight.
Your drain setup must also respect the height measurements. The drain hose should be connected between 40 cm and 100 cm above the ground. This height helps the machine drain water safely and prevents siphoning issues.
6. Use an Extension Hose if Needed
If the standard drain hose is not long enough to reach your waste pipe, you can use an approved extension hose. The visuals mention a maximum extension length of 3.2 meters. When using an extension, make sure all connections are tight and that the hose remains elevated within the recommended height range.
7. Fix the Hose to the Plastic Holder
Your washing machine includes a plastic hose holder on the back panel. Insert the drain hose into this holder to keep it stable. Securing the hose prevents movement and avoids clinking noises when the machine operates, especially during high spin cycles.
8. Check the Main Power Socket
Before plugging in the machine, test the wall socket using another device, such as a lamp or phone charger. This confirms that the outlet is working correctly. A stable power source is necessary for the washing machine to run safely.
9. Connect the Power Cable
Plug the washing machine directly into the wall socket. Avoid using extension cords or multi plug adapters, because they may overheat or fail under the machine’s power load. A direct connection ensures safe operation and consistent electrical flow.
Once all connections are complete and secure, your Beko washing machine is ready for a test cycle. Run a quick rinse program without laundry to confirm that the water inlet, drainage, and power system are functioning correctly.
For installation details on removing transit bolts and power connection see How to Install your Washing Machine (Part1)
